XVR301-04Q3 4-Channel 1 SATA XVR

Description The Uniview XVR301-04Q3 is a reliable 4-channel hybrid video recorder designed for small to medium surveillance systems such as homes, shops, and offices. It supports multiple camera technologies including AHD, TVI, CVI, CVBS, and IP cameras, providing flexible integration with existing security setups. The device delivers efficient video compression and high-resolution output up to 4K, ensuring clear monitoring and recording performance. Key Features 4-Channel Video Input – Supports up to 4 analog cameras Hybrid Support – Works with AHD / TVI / CVI / CVBS / IP cameras IP Camera Support – Up to 2 IP cameras (expandable up to 6 channels) Video Compression – H.265 / H.264 for efficient storage 4K HDMI Output – High-quality video display Remote Monitoring – Mobile and PC access Two-Way Audio Support Simultaneous HDMI & VGA Output The system is designed to provide flexible connectivity with mainstream camera protocols such as ONVIF and RTSP, making it compatible with various brands. Technical Specifications Model: XVR301-04Q3 Channels: 4 Channel Storage: 1 SATA HDD (Up to 8TB) Max Recording Resolution: 8MP Lite / 5MP Lite / 4MP / 1080P Video Output: HDMI (up to 4K), VGA, CVBS Audio Input/Output: 1 Channel RCA USB Ports: 2 × USB 2.0 Network: 1 × RJ45 (10/100 Mbps) Playback: 4 Channel synchronous playback Weight: Approx. 1–1.1 kg The recorder supports multiple recording resolutions including 8MP Lite, 5MP Lite, 4MP, and 1080P, allowing flexibility based on camera capability and storage requirements. Typical Applications Home security systems Retail shops Offices and small businesses Warehouses Schools and institutions This model is commonly used where 4 cameras with future IP expansion are required.
